HBM PW2D Single Point Load Cell Weighs a Maximum Load High Speed Highly Dynamic Weighing Tasks Involving Short Cycle Times for DIY Electronic(PW2DC3 36KG)
5.0 (37 items)
Limited Time SaleUS$150.19 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 221500139 | Release Date | 2026/05/03 | List Price | US$100.13 | Model Number | 221500139 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specifications:Theory : Resistance SensorUsage : Pressure SensorMaterial : MetalType : Magnetic SensorOutput : Analog SensorType : Load Cell/Force SensorAccuracy class : C3 Multi Range (MR)Number of load cell verification intervals : 3000nLCMaximum capacity : 7.2-72KGMinimum LC verification interval : 0.5-10gRatio of minimum verification interva : 14400,12000,9000Ratio of minimum verification interva(36-72kg) : 7200Temperature effect on zero balance : ±0.0097,±0.0116,±0.0155,±0.0194,±0.0194Accuracy class according to NTEP : III SSensitivity : 2.0±0.2(Option 6: A = 2mV/V ±0.1%)Zero signa : 0±0.1Temperature coefficient of sensitivity In the range +20 - +40°C [+68 - +104°F] In the range -10 - +20°C [+14 - +68°F] : ±0.0175,±0.0117Relative reversibility error : ±0.0166Linearity deviation : ±0.0166Minimum dead load output return : ±0.0166Off-center load error : ±0.0233Input resistance : 300 - 500Output resistance : 300 - 500(Option 6: A = 410 ±0.2 )Reference excitation voltage : 5Nominal range of excitation voltage : 1-12Maximum excitation voltage : 15Isolation resistance at 100 VDC : >2Nominal (rated) range of ambient temperature : -10 - +40 [+14 - +104°F]Operating temperature range : -10 - +50 [+14 - +122°F]Storage temperature range : -25 - +70 [+13 - +158°F]Limit load at max. 160 mm eccentricity : 150Lateral load limit, static : 300Service load at max. 100 mm eccentricity : 150Breaking load at max. 20 mm eccentricity : 300Relative permissible oscillation stress at max.20 mm eccentricity : 70Weight, approx : 0.25Degree of protection : IP67Material Measuring body Application protection Cable sheath : Aluminum Silicone caoutchouc PVC
- Number of load cell verification intervals : 3000nLC Maximum capacity : 7.2-72KG
- Minimum LC verification interval : 0.5-10g Ratio of minimum verification interva : 14400,12000,9000
- Ratio of minimum verification interva(36-72kg) : 7200 Temperature effect on zero balance : ±0.0097,±0.0116,±0.0155,±0.0194,±0.0194
- Accuracy class according to NTEP : III S Sensitivity : 2.0±0.2(Option 6: A = 2mV/V ±0.1%)
- Zero signa : 0±0.1 Temperature coefficient of sensitivity In the range +20 - +40°C [+68 - +104°F] In the range -10 - +20°C [+14 - +68°F] : ±0.0175,±0.0117
- Relative reversibility error : ±0.0166 Linearity deviation : ±0.0166
| Color | Silver |
|---|---|
| Brand Name | JCKJEDAT |
| Part Number | TFYATFJCU-SILVER-PW2DC336KG |
| Manufacturer | JCKJEDAT |
| Weight Capacity Maximum | 1 Grams |
